Communication Interface
-
2 independent DSI3 interfaces compliant with the protocol standard: DSI3 Bus Standard (Revision 1.00, February 16, 2011)
Supported Connection Methods
-
Point-to-Point
-
Parallel Bus
- Daisy Chain Bus
Multiple Online Configuration Functions
-
Supports up to 15 DSI3 slave nodes
-
Supports up to 16 data packets per frame
-
Supports modifying waveform smoothness to optimize EMC performance
Supported Operating Modes
-
CRM: Command Response Mode
-
PDCM: Periodic Data Collection Mode
-
BDM: Background Diagnostic Mode
- DM: Slave Address Allocation Mode
Application
-
Ultrasonic Parking Assistance System
- DSI3 Bus Network
Functional Safety
-
AEC-Q100 Grade 2
-
Compliant with ISO 26262 Functional Safety Level ASIL-B
